SECURITY Detection


MSD MRI FMD Screening Solution

High performance, portable MRI FMD screening solution








Visit us at
Passenger Terminal Expo
London - United Kingdom
Mar 26 - 28, 2019
Exhibitor: CEIA S.p.A. - Booth 1065

ISC West
Las Vegas, NV - United States of America
Apr 10 - 12, 2019
Exhibitor: CEIA USA Ltd. - Booth 12132

Airport Show Dubai
Dubai - United Arab Emirates
Apr 29 - May 1, 2019
Exhibitor: CEIA S.p.A. - Booth 4221

See all upcoming events >>

  • Multi-Zone indication to quickly find the ferrous items on your patients or staff unlike other products on the market
  • Extremely budget friendly
  • Technology automatically adjusts for difficult environments
  • Alternate alerts via bluetooth headset
  • 26 hours battery life
  • For ferrous metal check post and pass through operations
  • No installation cost - ready for immediate use


Manuals

MSD MRI FMD Screening Solution

Target pinpointing indication; ready for immediate use; one-piece and lightweight design (total weight only 21 lbs); extremely durable design

Specifications

Controls and indicators

  • ON/OFF push-button
  • 4-key keypad, for programming and status readout
  • Security: Programming Access protected by User and Super User password
  • Power indicator: White lamp
  • Alarm indicator
    • Green light: normal operation, no detection
    • Red light: target detection over the alarm threshold / Fault indication
    • Blue light: connecting Bluetooth device in progress
  • Graphic display: Messages during use, programming and self-diagnosis alerts
  • Multi-color status indicator
    • Green light: normal operation, no detection
    • Yellow light: proportional target detection under the alarm threshold
    • Red light: Continuous light: target detection over the alarm threshold; 5 different zone indication; Blinking light: fault
    • Blue light: connecting Bluetooth device in progress
  • Alarm Sounder
    • Alarm indication for target over the alarm threshold, with fixed or proportional pitch
    • Warning and alarm indications adjustable in continuous/pulsed tone and volume
    • Battery low: double beep
    • Self-diagnosis alert: intermittent tone
  • Bluetooth headset
    • Warning indication for target under the alarm threshold, with fixed or proportional pitch
    • Alarm indication for target over the alarm threshold, with fixed or proportional pitch
    • Warning and alarm indications adjustable in continuous/pulsed tone and volume
    • Battery low: double beep
    • Diagnosis: intermittent tone

Power supply

  • AC/DC external power adapter: 100 … 240 V~ , 47…63Hz, 40W
  • Embedded rechargeable battery
    • 16h typical / 17h max. of continuous operation with 3 h battery charge
    • 24h typical / 26h max. of continuous operation with 4.5 h battery charge

Detector environmental conditions

  • Working temperature: 14 to 149°F
  • Storage temperature: -35 to 158°F
  • Relative humidity: 0 to 95%, non-condensing

Weight

  • MSD: 21 lbs
  • AC/DC adapter: 1.6 lbs
  • Bluetooth kit: 0.5 lbs (includes battery charger)
  • Carrying case: 1.5 lbs
  • Installation kit: 0.6 lbs

MSD dimensions

  • Height: 75”; Width: 13”

Shipping information

  • Dimensions (WxDxH) 16” x 79” x 19”
  • Weight 53 lbs

Detector degree of protection

  • Fully weather proof for outdoor use (IP65)

Available accessories

  • EVO function activation: ordering code 88918
  • Additional Bluetooth headset: ordering code 70628 (one Bluetooth headset included)
  • MSD-RRU Remote Relay Unit: ordering code MSD-RRU
  • Wall mounting kit: ordering code 67258

Certification and compliance

  • Non-emitting device: safe for use for pace-makers and other medical implants
  • Compliant and certified to the applicable electromagnetic Standards on Human Exposure and pacemaker safety
  • Compliant with and certified to the applicable International Standards for electrical safety and EMC
